Ktm 2027 KTM SX-E 2.12 2027E 2.12 - STEP IT UP

DescriptionSpecifications

The all-new 2027 KTM SX-E 2.12 takes all the best parts from the KTM SX-E 2, but steps it up with a taller frame, bigger 12" front wheel, and extended > Read more

GRAPHICS

Using the full-sized KTM SX range as a guideline, the KTM SX-E 2.12 features modern, striking graphics in typical "big bike" fashion. All graphics are also applied using an in-mold process, ensuring the best durability and quality for many years of off-road action.

CHASSIS

Built tough to last, the KTM SX-E 2.12 chassis boasts an impressive list of construction materials. The upper triple-clamp, handlebar clamps, footrest carrier, and brake components are made of high-end forged aluminum alloys, while the lower triple clamps and the shaft are crafted from forged chromoly steel. The swingarm and skid plate complete the list, made from HPDC aluminum alloy.

FRAME

The KTM SX-E 2.12 features a slightly modified version of the center tube Aluminum Extrusion Frame design found on the KTM SX-E 2. Constructed from High-End Aluminum alloy, this frame strikes the perfect balance between strength and safety, while the high-quality glass-fiber reinforced subframe features an impact-resistant plastic composite for low weight and shock absorption.

SUSPENSION

The KTM SX-E 2.12 boasts a non-adjustable, WP regular Hydraulic Fork with a slightly longer range compared to the KTM SX-E 2. This extends the proportional elements of the platform, while maintaining a preload-adjustable 34 mm Hydraulic-mono-shock with separation piston on the rear.

WHEELS AND TIRES

If you were wondering what the last two digits in SX-E 2.12 referred to, it's the 12" front wheel matched to a 10" rear, setting it apart from the KTM SX-E 2. Made from lightweight aluminum, both HPDC rims, front and rear, are powder-coated to provide trouble-free maintenance, while a set of exceptionally well-balanced motocross tires from KENDA provides ample grip.

INCREASED SEAT HEIGHT

The KTM SX-E 2.12 is aimed at bigger beginners with a 2.59 in (66 mm) taller seat height when compared to the KTM SX-E 2. This was achieved by increasing the bench thickness, chassis dimensions, and bodywork to better in line with overall proportions.

BRAKES

Slightly longer brake lines are added to fit within the larger proportions of the KTM SX-E 2.12. These sent fluid to a set of radial, hydraulic 140 mm disk brakes on the front and rear, ensuring ample stopping power when the going gets too fast. Also, the hand levers are adjustable to fit smaller hand sizes, with the brake pads being compatible with high-end market bicycle brake pads for easy availability.

CONTROLS

The black anodized, aluminum alloy handlebars feature 25 mm bar raisers, but maintain a reduced diameter grip area for the perfect ergonomic grip for little hands. The width and bend were also specifically developed for easy steering while ensuring a firm grip and control of the KTM SX-E 2.12.

LIGHT WEIGHT

Weighing in at only 29 kg, the KTM SX-E 2.12 feels like a real, bigger motorcycle, while still providing easy handling. The combination of weight and agility provides a planted, more secure feeling as the speed builds, and is better suited to bigger, harder bumps.

MOTOR AND POWER

Providing the forward drive for the KTM SX-E 2.12 is a lightweight, maintenance-free 1,8 kW HUB Motor which delivers a maximum of 50 Nm. The "HUB-Motor-Concept" is void of additional parts like chains or sprockets, helping to keep the weight low and providing extra safety in the event of a crash. The controller is also integrated within the motor packaging, guaranteeing a spontaneous, but controllable power delivery.

CHARGER

An external charger supplying up to 500 W can be connected to any 110- or 230-Volt socket and plugs directly into the battery pack for easy charging. Charging time from 0 - 80% take approximately 35 minutes, with a full 100% charge achieved in less than 60 minutes.

SAFETY

Making sure your little ripper is safe is a top priority. For that reason, the KTM SX E-2.12 is fitted with a roll-over sensor that cuts power in the event of a crash or tip-over. A wrist lanyard key also provides a direct connection between the riders and the kill switch, which stops the motor in the event of an uncontrollable riding scenario.

MULTIFUNCTIONAL THROTTLE

As an added safety feature to ensure the KTM SX-E 2.12 doesn't pull away without warning, the electric motor is activated by rolling the throttle forward. Once on, a haptic 'vibration' is sent through the grip, indicating to the rider that the bike is ready to go. This and an illuminated multifunctional display located next to the throttle, makes keeping an eye on selected ride modes and battery life is a breeze, with different colors indicating which ride mode is selected, as well as what level the battery is at.

QUICK CHANGE LITHIUM-ION BATTERY

Powering the KTM SX E-2.12 comes courtesy of a 9.4 Ah, Lithium-ion power-tool-type battery with proven longevity and robustness, boasting 1500 charging cycles and up to 100 minutes of riding time. However, the real perk comes with the ease of swapping the battery with one easy movement, providing advantages like anti-ride protection, extended ride time with multiple batteries, and easy battery replacement in case of damage. Moreso, all units are rated IP65 and perfectly protected from wet conditions.

Premium Manufacturer's Warranty

This motorcycle comes with a Premium Manufacturer's Warranty. Riders enjoy up to 1 year of coverage and experience the thrill of offroad riding with added peace of mind. To keep the warranty valid, always follow the guidelines outlined in your motorcycle's Owner's Manual, including using the bike as intended and completing all scheduled services at an authorized KTM dealer. The standard manufacturer's warranty conditions, as specified in the delivery certificate, also remain applicable. More information and details on how to benefit from this offer can be found on the KTM warranty page. Valid from Model Year 2027 onwards for all offroad motorcycles as well as the 450 SMR.

View More Info on KTM Website

Engine
Electric motor	3 phase 36 V - BLDC geared-Hub-motor with outer rotor
Max. power	1,8 kW
Torque	50 Nm
Max. motor speed	3000 rpm
Charging time 100 %	60 min.
Rated output	0,75 kW
Traction battery	Husqvarna 40-B330X / Lithium-Ion
Charger line voltage	EU: 220-240V 50-60Hz / US: 100-240V 50-60 Hz
Charging power	500 W
Charging time 80 %	35 min.
Chassis
Frame design	Central tube Aluminium frame
Rear subframe design	Glass fiber reinforced plastic
Handlebar	Tapered aluminum Ø 22/18 mm
Front brake	Disc brake
Rear brake	Disc brake
Front brake disc diameter	140 mm
Rear brake disc diameter	140 mm
Tyre width (front)	2.5
Tyre height (front)	12
Tyre width (rear)	2.5
Tyre height (rear)	10
Steering head angle	63 °
Suspension
Front suspension	WP regular-side-Down fork, Ø 30 mm
Rear suspension	WP monoshock
Suspension travel (front)	90 mm
Suspension travel (rear)	70 mm
Steering head angle	63 °
Fork offset	15 mm
Dimensions
Seat height	536 mm
Weight (without fuel)	27 kg
Wheelbase tolerance	0.39 inch
Ground clearance	168 mm
