Ktm 2026 KTM 250 XC 2026CROSS COUNTRY LEGEND

DescriptionSpecifications

At the forefront of cross-country racing, the KTM 250 XC sets a benchmark for performance. With one of the most powerful engines in its class, it features > Read more

Easy Suspension Adjustment

As always, the suspension boasts an easy tool-free setup at both ends, ensuring you chase down the podium in total control. On the rear, a hand-adjustable dual compression option allows riders to adjust high- and low-speed settings in a matter of seconds. The forks on the front end are also easily modified thanks to hand-adjustable clickers on the bottom of the fork shoe and top cap.

AIRBOX

The robust one-piece design airbox on the KTM XC range features an air inlet sleeve and snorkel, which prevents deformation and improves airflow. But don't fret, toolless filter access is retained, with an intuitive filter mounting system and protection against dirt intrusion.

More Usable Power

The KTM 250 XC has always represented the very best of unsurpassed power and lightweight construction. The simplicity and low maintenance cost of the 2-Stroke motor have made it a favorite amongst hard-core cross country racers for generations., The KTM 250 XC enters the pits with the same legendary performance and low engine weight of only 23,9 kg - and a mission to maintain its benchmark as the one to beat.

Fuel Injection

With Electronic Fuel Injection setting the standard, there's no more jetting setup pre-race, and thanks to the Keihin EFI, the ECU coming from Vitesco and reed valve case design, you can be guaranteed of laying down optimal power at any altitude, all of the time.

Selectable Maps

The KTM XC models feature a map select switch as standard, allowing the racer to switch between 2 perceptible engine maps. Map 1 provides a linear, predictable power delivery, while Map 2 gives it the full beans with crisp, explosive power output.

Absolute Control

No matter how gnarly the trail is, you'll stay in complete control thanks to a rider-focussed frame design that has not only been engineered for longitudinal rigidity, but also repositions rotating mass closer to the center of gravity. Thick frame walls also improve reliability, flex characteristics and offer unmatched rider feel. The shock mounting also provides the perfect amount of anti-squat for better traction out of corners, while the footpeg mounting position is positoned in such a way to reduce the risk of hooking up on roots or rocks. Additionally, forged brackets on the lower frame rails allows for easy installation of the skid plate, too.

Ergonomics

The KTM XC and XC-F range feature tank shrouds with bi-compound plastics, which work alongside the specially-developed rider triangle, providing unmatched knee contact and gripping surfaces - especially when standing on the pegs. While the plastics work to expel mud buildup in wet, muddy conditions, the flat seat profile and high-grip black seat cover provide exceptional rider movement and control. A handy grip pocket under the seat, just above the airbox, makes gripping the bike and lifting it much easier.

Go the distance

You call it a fuel tank. We call it a 8.5 liters race bucket. The transparent polythene fuel tank has a fuel tank roll - which not only secures the tank more firmly in place, and allows for easy fuel level monitoring - it also protects the frame from unwanted scrubbing and race rash.

Energy absorption

Besides the expertly crafted, hydro-formed, laser-cut, and robot-welded frame being engineered to provide exceptional rider feedback and straight-line stability, the chassis consists of specifically calculated parameters of longitudinal and torsional flex. This means the frame acts as a "shock absorber" of sorts, making for a less harsh ride, resulting in less rider fatigue over many hard laps.

WP XACT Fork

Let's get the technical parts out of the way first; the 48 mm WP XACT Closed Cartridge spring forks fitted to the KTM XC and XC-F line-up feature progressive and consistent damping, while oil and air bypasses reduce pressure peaks. In combination with the mid-valve damping system, all this provides exceptional feedback and rider comfort. The fork also has settings which not only complement the frame and rear linkage, but ensure stellar performance at all levels. Speaking of settings, these are easily adjusted via easy-access click adjusters for compression and rebound.

WP XACT Shock

Keeping things in check at the rear, the WP XACT rear shock uses settings directly from the KTM Factory Racing Teams. The frame and shock geometry mean more ground clearance at the linkage, making it less susceptible to bottoming out. Small diameter linkage bolts save weight, while linkage seals refine rear shock response and advanced damping characteristics.

Ultimate rigidity

Count on a durable chain guide and chain guard and minimize the chances of hooking on external objects - especially in extremely muddy terrain while reducing dirt build-up around the swingarm and rear sprocket. For 2026 we've also modified the fixing points and routing of the wiring harness so it's less prone to wear and damage.

Consistency

A 66.4 mm bore, highly innovative electronic exhaust port management, and a machined finish for accurate port timing means the cylinder on the KTM 250 XC does more than just house the piston. It results in much-improved rideability, engine control, and more adjustability of the engine characteristics, thanks to 2 selectable and distinguished engine maps. Also, it's auto-calibrating, meaning there's no more hassle with wrong power valve adjustments.

View More Info on KTM Website

Engine
Design	1-cylinder, 2-stroke engine
Displacement	249 cm³
Transmission	6-speed
Fuel-mixture generation	Keihin EFI, throttle body 39 mm
EMS	Vitesco Technologies EMS
Clutch primary drive teeth	72
Clutch	Wet, DDS multi-disc clutch, Brembo hydraulics
Engine cylinder	Single cylinder
Engine stroke	2-Stroke
Chassis
Frame design	Central double-cradle-type 25CrMo4 steel
Front brake	Disc brake
Rear brake	Disc brake
Rear subframe design	Aluminum-reinforced polyamide
Chain	520 X-Ring
Suspension
Front suspension	WP XACT Closed Cartridge Ø 48 mm
Rear suspension	WP XACT Monoshock with linkage
Suspension travel (front)	300 mm
Suspension travel (rear)	300 mm
Suspension travel (front)	11.81 inch
Suspension travel (rear)	11.81 inch
Front suspension adjustment	Compression (high and low speed), rebound
Rear suspension adjustment	Preload adjuster
Dimensions
Seat height	954 mm
Ground clearance	354 mm
Ground clearance	13.94 inch
Tank capacity (approx.)	9 l
Tank capacity (approx.)	2.38 US gal
Weight (without fuel)	101.8 kg
